Details
Features
- Adopt high lumen Samsung 5630 led chip
- Using high quality power supply,PF>0.9
- Color Rendering Index(CRI)>80
- With 3 years warranty
- Energy saving up to 50%.even lighting output.
- Wide range of input voltage: AC 100~240V.
- Instant start, no flicking, no humming.
Parameters
Model Name | FV-PA-1200*600-5630 |
Input voltage | AC 100~240V or 24V DC |
Panel Input | DC 55~70V (700 mA) |
LED Source | 240 pcs Samsung 5630 led chip |
Power consumption | 85W |
luminous flux | 4860 lm(white) |
3580lm(warm white) | |
Color | Warm white |
White | |
Color temperature | 2500~4000k(Warm white) |
4000~7000k(White) | |
Life time | >50,000 Hour |
Operating temperature | -20ºC to + 50ºC |
Storage temperature | -30ºC to + 60ºC |
Luminosity | >862Lux(1.meter, White) |
>786Lux(1.meter, Warm white) | |
Certificates | CE . RoHS |
Weight | 4.16 KGS |
Size | 1195X595X10 mm |
Water proof | IP20 |
Part number | Color | Voltage | Current | Power | Luminous Flux |
FV-PA-1200*300-W | White | DC 55~70V | 700 mA | 85W | 4860 lm |
FV-PA-1200*300-WW | Warm white | DC 55~70V | 700 mA | 85W | 3580 lm |
