Details
Features
- Available in 12V DC maximum
- Very bright & low power consumption
- Operating temperature: -20°C~50 °C
- Long life span LED lights, more than 50,000 hours+.
- Adhesive back, peel& stick!
- Super thin, 8mm only.
- Dimmable to 6V DC.
- Non-Waterproof, IP20.
Applications
Ideal for sign letters and channel letters, concealed lights,indoor only
Parameter
| Mini Module series : 3528+335 1LED/Module | |||||||
| Part number |
|
LED QTY/Module | Lumen/Module | Voltage | Power/Module | packing means | |
| FV-MD-NW3528+335R-12-3 | Red | 3 | 6 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335Y-12-3 | Yellow | 3 | 6 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335B-12-3 | Blue | 3 | 7.5 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335G-12-3 | Green | 3 | 12 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335W-12-3 | white | 3 | 15---19.5 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335WW-12-3 | warm White | 3 | 12---18 | DC12V | 0.24 watt | 50 / link | |
| FV-MD-NW3528+335P-12-3 | pink | 3 | 6 | DC12V | 0.24 watt | 50 / link | |
