Product Feature
- Lower consumption,high brightness.
- High-strength aluminum alloy
- Aluminum alloy brackets,easily installation.
- Strongly shock resistance.
- Adopt high lumen LED Chip,with high effective
- Light-emiting area is uniform,high brightness
- High power factor power supply
- Adpot to Rohs standard,without leaded and mercury.
Application
- Place of business
- Home Furnishing lighting
- Exhibition lighting
- Officical business lighting.
- Outdoor usage,like decoration lighting.
Spec.
|
Item |
Parameter |
|
Model name |
FV-T5-60 |
|
Description |
T5 60cm LED Tube |
|
Input Voltage |
AC 175V~265V |
|
Output Wattage |
6±0.5W |
|
Emiting Angle |
110° |
|
Color |
Cool White(CK：6000~6500K) Warm white(CK：2700~3000K) |
|
Working Temperature |
-20℃~40℃ |
|
Working Humidity |
5%~95% |
|
Storage Temperature |
-20℃~80℃ |
|
Materials |
PC , Al |
|
Driver Type |
Non-insulated and built-in driver |
|
Life Span |
>25,000hours |
|
Color Rendering Index |
>70 |
|
Lumen |
Cool white:1600 lm±10% Warm white:1500 lm±10% |
|
Central Illumination(H:3m) |
Cool white:55±10%（Lux） Warm white:52±10%（Lux） |
|
Each Package Dimension: （with bracket） |
1195*60*48mm |
|
Qty/carton(with bracket) |
50pcs |
|
Outcarton Dimension （with bracket） |
1210*315*495mm |
|
Each Package Dimension （without bracket） |
1195*40*40mm |
|
Package qty （without bracket） |
100pcs |
|
Outcarton Dimension （without bracket） |
1210*415*415mm |
