Details

Product Feature

  1. Lower consumption,high brightness.
  2. High-strength aluminum alloy
  3. Aluminum alloy brackets,easily installation.
  4. Strongly shock resistance.
  5. Adopt high lumen LED Chip,with high effective
  6. Light-emiting area is uniform,high brightness
  7. High power factor power supply
  8. Adpot to Rohs standard,without leaded and mercury.

Application

  1. Place of business
  2. Home Furnishing lighting
  3. Exhibition lighting
  4. Officical business lighting.
  5. Outdoor usage,like decoration lighting.

Spec.



Item

Parameter

Model name

FV-T5-90

Description

T5 90cm LED Tube

Input Voltage

AC 175V~265V

Output Wattage

9±0.5W

Emiting Angle

110°

Color

Cool White(CK:6000~6500K)

Warm white(CK:2700~3000K)

Working Temperature

-20℃~40℃

Working Humidity

5%~95%

Storage Temperature

-20℃~80℃

Materials

PC , Al

Driver Type

Non-insulated and built-in driver

Life Span

>25,000hours

Color Rendering Index

>70

Lumen

Cool white:1400 lm±10%

Warm white:1300 lm±10%

Central Illumination(H:3m)

Cool white:45±10%(Lux)

Warm white:40±10%(Lux)

Each Package Dimension:

(with bracket)

900*60*48mm

Qty/carton(with bracket)

50pcs

Outcarton Dimension

(with bracket)

910*320*495mm

Each Package Dimension

(without bracket)

915*40*40mm

Package qty

(without bracket)

100pcs

Outcarton Dimension

(without bracket)

1210*415*415mm
